Descriptions |
|
|
• Measurement
range: 5-500m/6-550 yds. |
• First
Target Priority mode is employed
When measuring overlapping subjects, the distance of
the closest subject is displayed — useful when
golfing for measuring the
distance to a flagstick on
a green with woods in the background. |
• A
single press of the POWER button provides 8-second
continuous measurement, which enables measurement
even with slight
hand movement |
• Compact,
lightweight (approx. 125g) and ergonomic design |
• Distance
measurement display step is 1m/yd. |
• High-quality
6x monocular with multilayer coating for bright, clear
images |
• Long
eye relief design affords eyeglass wearers easy viewing |
| • Dioptre
adjustment function |
| • Long
eye relief design affords eyeglass wearers easy viewing |
| • Rainproof — JIS/IEC
protection class 4 (IPX4) equivalent (under our testing
conditions) |
| • Wide
temperature tolerance: -10°C to +50°C |
|
| |
|
|
|
| |
Internal display |
|
|
| |
1. Distance |
 |
| |
2. Unit of measure (m/yd.) |
| |
3. Target mark ( ) |
| |
4. Laser irradiation ( ) |
| |
5. Battery condition |
| |
|
| |
|
|
| |
|
|
|
| |
Specifications |
|
|
| |
|
|
|
| |
Measurement range |
5-500m/6-550
yds. |
| |
|
|
|
| |
Distance display (Increment) |
|
| |
|
|
|
| |
Accuracy* (actual distance) |
±1m/yd.
(shorter than 100m/yds.)
±2m/yds. (100m/yds. and over) |
| |
|
|
|
| |
Finder |
Magnification (x) |
6 |
| |
Effective objective diameter (mm) |
20 |
| |
Actual
field of view (º) |
6.0 |
| |
Exit pupil (mm) |
3.3 |
| |
Eye relief (mm) |
16.7 |
| |
|
|
|
| |
Dimensions (LxHxW) (mm) |
91
x 73 x 37 |
| |
|
|
|
| |
Weight (g) (excluding battery) |
125 |
| |
|
|
|
| |
Power source |
CR2
lithium battery x 1 (DC 3V)
Auto power shutoff function equipped (after 8 sec.) |
| |
|
|
|
| |
Laser
classification |
IEC60825-1:
Class 1M/Laser Product
FDA/21 CFR Part 1040.10: Class I Laser Product |
| |
|
|
|
| |
Electromagnetic
compatibility |
FCC
Part15 SubPartB class B, EU: EMC directive, AS/NZS,
VCCI classB, CU TR 020 |
| |
|
|
|
| |
Environment |
RoHS, WEEE |
| |
|
|
|
The specifications of the product may not
be achieved depending on the target object's shape, surface
texture and nature, and/or weather conditions. |
